Below are the specifications of the range of Mazda BT50 vans.
BT50 4X2 Single Cab| | BT50 4X2 Single Cab |
|---|
| Engine size (litres) | 2.5 |
|---|
| HP | 105 |
|---|
| Overall length (mm) | 5075 |
|---|
| Overall height (mm) | 1620 |
|---|
| Overall width (mm) | 1715 |
|---|
| Wheelbase (mm) | 2985 |
|---|
| Loading Height (mm) | 669 |
|---|
| Rear Door Width (mm) | 1328 |
|---|
| Rear Door Height (mm) | 465 |
|---|
| Load Length (mm) | 2280 |
|---|
| Load Width Max (mm) | 1456 |
|---|
| Load Height (mm) | 465 |
|---|
| Load Volume (m3) | n/a |
|---|
| Gross Payload (Kg) | 1208 |
|---|
| Gross Vehicle Weight (Kg) | 2800 |
|---|
| Kerb Weight (Kg) | 1630 |
|---|
| Towing Limit (Kg) | 1600 |
|---|
BT50 4×4 Double Cab TS| | BT50 4×4 Double Cab TS |
|---|
| Engine size (litres) | 2.5 |
|---|
| HP | 105 |
|---|
| Overall length (mm) | 5075 |
|---|
| Overall height (mm) | 1760 |
|---|
| Overall width (mm) | 1805 |
|---|
| Wheelbase (mm) | 3000 |
|---|
| Loading Height (mm) | 805 |
|---|
| Rear Door Width (mm) | 1328 |
|---|
| Rear Door Height (mm) | 465 |
|---|
| Load Length (mm) | 1530 |
|---|
| Load Width Max (mm) | 1456 |
|---|
| Load Height (mm) | 465 |
|---|
| Load Volume (m3) | n/a |
|---|
| Gross Payload (Kg) | 1137 |
|---|
| Gross Vehicle Weight (Kg) | 3030 |
|---|
| Kerb Weight (Kg) | 1855 |
|---|
| Towing Limit (Kg) | 3000 |
|---|
BT50 4×4 Single Cab| | BT50 4×4 Single Cab |
|---|
| Engine size (litres) | 2.5 |
|---|
| HP | 105 |
|---|
| Overall length (mm) | 5075 |
|---|
| Overall height (mm) | 1745 |
|---|
| Overall width (mm) | 1805 |
|---|
| Wheelbase (mm) | 3000 |
|---|
| Loading Height (mm) | 803 |
|---|
| Rear Door Width (mm) | 1328 |
|---|
| Rear Door Height (mm) | 465 |
|---|
| Load Length (mm) | 2280 |
|---|
| Load Width Max (mm) | 1456 |
|---|
| Load Height (mm) | 465 |
|---|
| Load Volume (m3) | n/a |
|---|
| Gross Payload (Kg) | 1212 |
|---|
| Gross Vehicle Weight (Kg) | 3010 |
|---|
| Kerb Weight (Kg) | 1805 |
|---|
| Towing Limit (Kg) | 3000 |
|---|
