Below are the specifications of the range of Toyota Dyna vans.
Dyna 3.0D-4D LWB Dropside| | Dyna 3.0D-4D LWB Dropside |
|---|
| Engine size (litres) | 3.0 |
|---|
| HP | 109 |
|---|
| Overall length (mm) | 5993 |
|---|
| Overall height (mm) | 2235 |
|---|
| Overall width (mm) | 2000 |
|---|
| Wheelbase (mm) | 3350 |
|---|
| Loading Height (mm) | 896 |
|---|
| Rear Door Width (mm) | 1600 |
|---|
| Rear Door Height (mm) | 380 |
|---|
| Load Length (mm) | 4460 |
|---|
| Load Width Max (mm) | 2000 |
|---|
| Load Height (mm) | 400 |
|---|
| Load Volume (m3) | n/a |
|---|
| Gross Payload (Kg) | 1280 |
|---|
| Gross Vehicle Weight (Kg) | 3500 |
|---|
| Kerb Weight (Kg) | 2220 |
|---|
| Towing Limit (Kg) | 2200 |
|---|
Dyna 3.0D-4D MWB Dropside| | Dyna 3.0D-4D MWB Dropside |
|---|
| Engine size (litres) | 3.0 |
|---|
| HP | 109 |
|---|
| Overall length (mm) | 4663 |
|---|
| Overall height (mm) | 2231 |
|---|
| Overall width (mm) | 2000 |
|---|
| Wheelbase (mm) | 2545 |
|---|
| Loading Height (mm) | 896 |
|---|
| Rear Door Width (mm) | 1600 |
|---|
| Rear Door Height (mm) | 380 |
|---|
| Load Length (mm) | 3130 |
|---|
| Load Width Max (mm) | 2000 |
|---|
| Load Height (mm) | 400 |
|---|
| Load Volume (m3) | n/a |
|---|
| Gross Payload (Kg) | 1525 |
|---|
| Gross Vehicle Weight (Kg) | 3500 |
|---|
| Kerb Weight (Kg) | 1975 |
|---|
| Towing Limit (Kg) | 2200 |
|---|
Dyna 3.0D-4D SWB Dropside| | Dyna 3.0D-4D SWB Dropside |
|---|
| Engine size (litres) | 3.0 |
|---|
| HP | 109 |
|---|
| Overall length (mm) | 4380 |
|---|
| Overall height (mm) | 2194 |
|---|
| Overall width (mm) | 1695 |
|---|
| Wheelbase (mm) | 2300 |
|---|
| Loading Height (mm) | 800 |
|---|
| Rear Door Width (mm) | 1600 |
|---|
| Rear Door Height (mm) | 380 |
|---|
| Load Length (mm) | 2852 |
|---|
| Load Width Max (mm) | 1695 |
|---|
| Load Height (mm) | 400 |
|---|
| Load Volume (m3) | n/a |
|---|
| Gross Payload (Kg) | 1280 |
|---|
| Gross Vehicle Weight (Kg) | 3000 |
|---|
| Kerb Weight (Kg) | 1710 |
|---|
| Towing Limit (Kg) | 2000 |
|---|
