Below are the specifications of the range of Vauxhall Movano vans.
Movano 28 2.5 CDTi 100 SWB l/r| | Movano 28 2.5 CDTi 100 SWB l/r |
|---|
| Engine size (litres) | 2.5 |
|---|
| HP | 100 |
|---|
| Overall length (mm) | 4899 |
|---|
| Overall height (mm) | 2253 |
|---|
| Overall width (mm) | 1990 |
|---|
| Wheelbase (mm) | 3078 |
|---|
| Loading Height (mm) | 545 |
|---|
| Rear Door Width (mm) | 1515 |
|---|
| Rear Door Height (mm) | 1632 |
|---|
| Load Length (mm) | 2714 |
|---|
| Load Width Max (mm) | 1764 |
|---|
| Load Height (mm) | 1670 |
|---|
| Load Volume (m3) | 8.0 |
|---|
| Gross Payload (Kg) | 985 |
|---|
| Gross Vehicle Weight (Kg) | 2800 |
|---|
| Kerb Weight (Kg) | 1815 |
|---|
| Towing Limit (Kg) | 2000 |
|---|
Movano 28 2.5 CDTi 146 SWB l/r| | Movano 28 2.5 CDTi 146 SWB l/r |
|---|
| Engine size (litres) | 2.5 |
|---|
| HP | 146 |
|---|
| Overall length (mm) | 4899 |
|---|
| Overall height (mm) | 2253 |
|---|
| Overall width (mm) | 1990 |
|---|
| Wheelbase (mm) | 3078 |
|---|
| Loading Height (mm) | 545 |
|---|
| Rear Door Width (mm) | 1515 |
|---|
| Rear Door Height (mm) | 1632 |
|---|
| Load Length (mm) | 2714 |
|---|
| Load Width Max (mm) | 1764 |
|---|
| Load Height (mm) | 1670 |
|---|
| Load Volume (m3) | 8.0 |
|---|
| Gross Payload (Kg) | 971 |
|---|
| Gross Vehicle Weight (Kg) | 2800 |
|---|
| Kerb Weight (Kg) | 1829 |
|---|
| Towing Limit (Kg) | 2000 |
|---|
Movano 32 2.5 CDTi 100 LWB h/r| | Movano 32 2.5 CDTi 100 LWB h/r |
|---|
| Engine size (litres) | 2.5 |
|---|
| HP | 100 |
|---|
| Overall length (mm) | 5899 |
|---|
| Overall height (mm) | 2490 |
|---|
| Overall width (mm) | 1990 |
|---|
| Wheelbase (mm) | 4078 |
|---|
| Loading Height (mm) | 538 |
|---|
| Rear Door Width (mm) | 1515 |
|---|
| Rear Door Height (mm) | 1874 |
|---|
| Load Length (mm) | 3714 |
|---|
| Load Width Max (mm) | 1764 |
|---|
| Load Height (mm) | 1912 |
|---|
| Load Volume (m3) | 12.6 |
|---|
| Gross Payload (Kg) | 1563 |
|---|
| Gross Vehicle Weight (Kg) | 3500 |
|---|
| Kerb Weight (Kg) | 1937 |
|---|
| Towing Limit (Kg) | 2000 |
|---|
Movano 33 2.5 CDTi 100 MWB h/r| | Movano 33 2.5 CDTi 100 MWB h/r |
|---|
| Engine size (litres) | 2.5 |
|---|
| HP | 100 |
|---|
| Overall length (mm) | 5399 |
|---|
| Overall height (mm) | 2493 |
|---|
| Overall width (mm) | 1990 |
|---|
| Wheelbase (mm) | 3578 |
|---|
| Loading Height (mm) | 541 |
|---|
| Rear Door Width (mm) | 1515 |
|---|
| Rear Door Height (mm) | 1874 |
|---|
| Load Length (mm) | 3214 |
|---|
| Load Width Max (mm) | 1764 |
|---|
| Load Height (mm) | 1912 |
|---|
| Load Volume (m3) | 10.8 |
|---|
| Gross Payload (Kg) | 1413 |
|---|
| Gross Vehicle Weight (Kg) | 3300 |
|---|
| Kerb Weight (Kg) | 1887 |
|---|
| Towing Limit (Kg) | 2000 |
|---|
Movano 33 2.5 CDTi 120 SWB h/r| | Movano 33 2.5 CDTi 120 SWB h/r |
|---|
| Engine size (litres) | 2.5 |
|---|
| HP | 120 |
|---|
| Overall length (mm) | 4899 |
|---|
| Overall height (mm) | 2496 |
|---|
| Overall width (mm) | 1990 |
|---|
| Wheelbase (mm) | 3078 |
|---|
| Loading Height (mm) | 545 |
|---|
| Rear Door Width (mm) | 1515 |
|---|
| Rear Door Height (mm) | 1874 |
|---|
| Load Length (mm) | 2714 |
|---|
| Load Width Max (mm) | 1764 |
|---|
| Load Height (mm) | 1912 |
|---|
| Load Volume (m3) | 9.1 |
|---|
| Gross Payload (Kg) | 1454 |
|---|
| Gross Vehicle Weight (Kg) | 3300 |
|---|
| Kerb Weight (Kg) | 1846 |
|---|
| Towing Limit (Kg) | 2000 |
|---|
Movano 35 2.5 120 LWB Maxi/r| | Movano 35 2.5 120 LWB Maxi/r |
|---|
| Engine size (litres) | 2.5 |
|---|
| HP | 120 |
|---|
| Overall length (mm) | 5899 |
|---|
| Overall height (mm) | 2720 |
|---|
| Overall width (mm) | 1990 |
|---|
| Wheelbase (mm) | 4078 |
|---|
| Loading Height (mm) | 537 |
|---|
| Rear Door Width (mm) | 1515 |
|---|
| Rear Door Height (mm) | 1874 |
|---|
| Load Length (mm) | 3714 |
|---|
| Load Width Max (mm) | 1764 |
|---|
| Load Height (mm) | 2147 |
|---|
| Load Volume (m3) | 13.9 |
|---|
| Gross Payload (Kg) | 1536 |
|---|
| Gross Vehicle Weight (Kg) | 3500 |
|---|
| Kerb Weight (Kg) | 1964 |
|---|
| Towing Limit (Kg) | 2000 |
|---|
Movano 35 2.5 146 Tech LWB h/r| | Movano 35 2.5 146 Tech LWB h/r |
|---|
| Engine size (litres) | 2.5 |
|---|
| HP | 146 |
|---|
| Overall length (mm) | 5899 |
|---|
| Overall height (mm) | 2490 |
|---|
| Overall width (mm) | 1990 |
|---|
| Wheelbase (mm) | 4078 |
|---|
| Loading Height (mm) | 538 |
|---|
| Rear Door Width (mm) | 1515 |
|---|
| Rear Door Height (mm) | 1874 |
|---|
| Load Length (mm) | 3714 |
|---|
| Load Width Max (mm) | 1764 |
|---|
| Load Height (mm) | 1912 |
|---|
| Load Volume (m3) | 12.6 |
|---|
| Gross Payload (Kg) | 1541 |
|---|
| Gross Vehicle Weight (Kg) | 3500 |
|---|
| Kerb Weight (Kg) | 1959 |
|---|
| Towing Limit (Kg) | 2000 |
|---|
Movano 35 2.5 CDTi 120 LWB h/r| | Movano 35 2.5 CDTi 120 LWB h/r |
|---|
| Engine size (litres) | 2.5 |
|---|
| HP | 120 |
|---|
| Overall length (mm) | 5899 |
|---|
| Overall height (mm) | 2490 |
|---|
| Overall width (mm) | 1990 |
|---|
| Wheelbase (mm) | 4078 |
|---|
| Loading Height (mm) | 538 |
|---|
| Rear Door Width (mm) | 1515 |
|---|
| Rear Door Height (mm) | 1874 |
|---|
| Load Length (mm) | 3714 |
|---|
| Load Width Max (mm) | 1764 |
|---|
| Load Height (mm) | 1912 |
|---|
| Load Volume (m3) | 12.6 |
|---|
| Gross Payload (Kg) | 1563 |
|---|
| Gross Vehicle Weight (Kg) | 3500 |
|---|
| Kerb Weight (Kg) | 1937 |
|---|
| Towing Limit (Kg) | 2000 |
|---|
Movano 35 2.5 CDTi 120 MWB h/r| | Movano 35 2.5 CDTi 120 MWB h/r |
|---|
| Engine size (litres) | 2.5 |
|---|
| HP | 120 |
|---|
| Overall length (mm) | 5399 |
|---|
| Overall height (mm) | 2493 |
|---|
| Overall width (mm) | 1990 |
|---|
| Wheelbase (mm) | 3578 |
|---|
| Loading Height (mm) | 541 |
|---|
| Rear Door Width (mm) | 1515 |
|---|
| Rear Door Height (mm) | 1874 |
|---|
| Load Length (mm) | 3214 |
|---|
| Load Width Max (mm) | 1764 |
|---|
| Load Height (mm) | 1912 |
|---|
| Load Volume (m3) | 10.8 |
|---|
| Gross Payload (Kg) | 1606 |
|---|
| Gross Vehicle Weight (Kg) | 3500 |
|---|
| Kerb Weight (Kg) | 1894 |
|---|
| Towing Limit (Kg) | 2000 |
|---|
Movano 35 2.5 CDTi 120 SWB h/r| | Movano 35 2.5 CDTi 120 SWB h/r |
|---|
| Engine size (litres) | 2.5 |
|---|
| HP | 120 |
|---|
| Overall length (mm) | 4899 |
|---|
| Overall height (mm) | 2496 |
|---|
| Overall width (mm) | 1990 |
|---|
| Wheelbase (mm) | 3078 |
|---|
| Loading Height (mm) | 545 |
|---|
| Rear Door Width (mm) | 1515 |
|---|
| Rear Door Height (mm) | 1864 |
|---|
| Load Length (mm) | 2714 |
|---|
| Load Width Max (mm) | 1764 |
|---|
| Load Height (mm) | 1912 |
|---|
| Load Volume (m3) | 9.1 |
|---|
| Gross Payload (Kg) | 1647 |
|---|
| Gross Vehicle Weight (Kg) | 3500 |
|---|
| Kerb Weight (Kg) | 1853 |
|---|
| Towing Limit (Kg) | 2000 |
|---|
