Below are the specifications of the range of Fiat Scudo vans.
Scudo L1H1 10 1.6JTD 90| | Scudo L1H1 10 1.6JTD 90 |
|---|
| Engine size (litres) | 1.6 |
|---|
| HP | 90 |
|---|
| Overall length (mm) | 4805 |
|---|
| Overall height (mm) | 1942 |
|---|
| Overall width (mm) | 1895 |
|---|
| Wheelbase (mm) | 3000 |
|---|
| Loading Height (mm) | 562 |
|---|
| Rear Door Width (mm) | 1237 |
|---|
| Rear Door Height (mm) | 1272 |
|---|
| Load Length (mm) | 2254 |
|---|
| Load Width Max (mm) | 1600 |
|---|
| Load Height (mm) | 1449 |
|---|
| Load Volume (m3) | 5.0 |
|---|
| Gross Payload (Kg) | 1000 |
|---|
| Gross Vehicle Weight (Kg) | 2661 |
|---|
| Kerb Weight (Kg) | 1661 |
|---|
| Towing Limit (Kg) | 2000 |
|---|
Scudo L1H1 12 2.0JTD 120| | Scudo L1H1 12 2.0JTD 120 |
|---|
| Engine size (litres) | 2.0 |
|---|
| HP | 120 |
|---|
| Overall length (mm) | 4805 |
|---|
| Overall height (mm) | 1942 |
|---|
| Overall width (mm) | 1895 |
|---|
| Wheelbase (mm) | 3000 |
|---|
| Loading Height (mm) | 562 |
|---|
| Rear Door Width (mm) | 1237 |
|---|
| Rear Door Height (mm) | 1272 |
|---|
| Load Length (mm) | 2254 |
|---|
| Load Width Max (mm) | 1600 |
|---|
| Load Height (mm) | 1449 |
|---|
| Load Volume (m3) | 5.0 |
|---|
| Gross Payload (Kg) | 1200 |
|---|
| Gross Vehicle Weight (Kg) | 2902 |
|---|
| Kerb Weight (Kg) | 1702 |
|---|
| Towing Limit (Kg) | 2000 |
|---|
Scudo L2H1 12 2.0JTD 120| | Scudo L2H1 12 2.0JTD 120 |
|---|
| Engine size (litres) | 2.0 |
|---|
| HP | 120 |
|---|
| Overall length (mm) | 5135 |
|---|
| Overall height (mm) | 1942 |
|---|
| Overall width (mm) | 1895 |
|---|
| Wheelbase (mm) | 3122 |
|---|
| Loading Height (mm) | 562 |
|---|
| Rear Door Width (mm) | 1237 |
|---|
| Rear Door Height (mm) | 1272 |
|---|
| Load Length (mm) | 2584 |
|---|
| Load Width Max (mm) | 1600 |
|---|
| Load Height (mm) | 1449 |
|---|
| Load Volume (m3) | 6.0 |
|---|
| Gross Payload (Kg) | 1200 |
|---|
| Gross Vehicle Weight (Kg) | 2932 |
|---|
| Kerb Weight (Kg) | 1732 |
|---|
| Towing Limit (Kg) | 2000 |
|---|
Scudo L2H2 12 2.0JTD 120| | Scudo L2H2 12 2.0JTD 120 |
|---|
| Engine size (litres) | 2.0 |
|---|
| HP | 120 |
|---|
| Overall length (mm) | 5135 |
|---|
| Overall height (mm) | 2276 |
|---|
| Overall width (mm) | 1895 |
|---|
| Wheelbase (mm) | 3122 |
|---|
| Loading Height (mm) | 562 |
|---|
| Rear Door Width (mm) | 1237 |
|---|
| Rear Door Height (mm) | 1630 |
|---|
| Load Length (mm) | 2584 |
|---|
| Load Width Max (mm) | 1600 |
|---|
| Load Height (mm) | 1750 |
|---|
| Load Volume (m3) | 7.0 |
|---|
| Gross Payload (Kg) | 1200 |
|---|
| Gross Vehicle Weight (Kg) | 2963 |
|---|
| Kerb Weight (Kg) | 1763 |
|---|
| Towing Limit (Kg) | 2000 |
|---|
