Below are the specifications of the range of Ford Transit vans.
Transit 260 2.2 TDCi SWB l/r 85| | Transit 260 2.2 TDCi SWB l/r 85 |
|---|
| Engine size (litres) | 2.2 |
|---|
| HP | 85 |
|---|
| Overall length (mm) | 4863 |
|---|
| Overall height (mm) | 2070 |
|---|
| Overall width (mm) | 1974 |
|---|
| Wheelbase (mm) | 2933 |
|---|
| Loading Height (mm) | 619 |
|---|
| Rear Door Width (mm) | 1540 |
|---|
| Rear Door Height (mm) | 1370 |
|---|
| Load Length (mm) | 2582 |
|---|
| Load Width Max (mm) | 1762 |
|---|
| Load Height (mm) | 1430 |
|---|
| Load Volume (m3) | 6.5 |
|---|
| Gross Payload (Kg) | 991 |
|---|
| Gross Vehicle Weight (Kg) | 2600 |
|---|
| Kerb Weight (Kg) | 1609 |
|---|
| Towing Limit (Kg) | 900 |
|---|
Transit 280 2.2 TDCi MWB l/r 110| | Transit 280 2.2 TDCi MWB l/r 110 |
|---|
| Engine size (litres) | 2.2 |
|---|
| HP | 110 |
|---|
| Overall length (mm) | 5230 |
|---|
| Overall height (mm) | 2047 |
|---|
| Overall width (mm) | 1974 |
|---|
| Wheelbase (mm) | 3300 |
|---|
| Loading Height (mm) | 596 |
|---|
| Rear Door Width (mm) | 1540 |
|---|
| Rear Door Height (mm) | 1370 |
|---|
| Load Length (mm) | 2949 |
|---|
| Load Width Max (mm) | 1762 |
|---|
| Load Height (mm) | 1430 |
|---|
| Load Volume (m3) | 7.4 |
|---|
| Gross Payload (Kg) | 1111 |
|---|
| Gross Vehicle Weight (Kg) | 2800 |
|---|
| Kerb Weight (Kg) | 1689 |
|---|
| Towing Limit (Kg) | 700 |
|---|
Transit 280 2.2 TDCi SWB l/r 110| | Transit 280 2.2 TDCi SWB l/r 110 |
|---|
| Engine size (litres) | 2.2 |
|---|
| HP | 110 |
|---|
| Overall length (mm) | 4863 |
|---|
| Overall height (mm) | 2070 |
|---|
| Overall width (mm) | 1974 |
|---|
| Wheelbase (mm) | 2933 |
|---|
| Loading Height (mm) | 619 |
|---|
| Rear Door Width (mm) | 1540 |
|---|
| Rear Door Height (mm) | 1370 |
|---|
| Load Length (mm) | 2582 |
|---|
| Load Width Max (mm) | 1762 |
|---|
| Load Height (mm) | 1430 |
|---|
| Load Volume (m3) | 6.5 |
|---|
| Gross Payload (Kg) | 991 |
|---|
| Gross Vehicle Weight (Kg) | 2600 |
|---|
| Kerb Weight (Kg) | 1609 |
|---|
| Towing Limit (Kg) | 700 |
|---|
Transit 300 2.2 TDCi MWB l/r 130| | Transit 300 2.2 TDCi MWB l/r 130 |
|---|
| Engine size (litres) | 2.2 |
|---|
| HP | 130 |
|---|
| Overall length (mm) | 5230 |
|---|
| Overall height (mm) | 2047 |
|---|
| Overall width (mm) | 1974 |
|---|
| Wheelbase (mm) | 3300 |
|---|
| Loading Height (mm) | 596 |
|---|
| Rear Door Width (mm) | 1540 |
|---|
| Rear Door Height (mm) | 1370 |
|---|
| Load Length (mm) | 2949 |
|---|
| Load Width Max (mm) | 1762 |
|---|
| Load Height (mm) | 1430 |
|---|
| Load Volume (m3) | 7.4 |
|---|
| Gross Payload (Kg) | 1309 |
|---|
| Gross Vehicle Weight (Kg) | 3000 |
|---|
| Kerb Weight (Kg) | 1691 |
|---|
| Towing Limit (Kg) | 1000 |
|---|
Transit 300 2.2 TDCi SWB l/r 130| | Transit 300 2.2 TDCi SWB l/r 130 |
|---|
| Engine size (litres) | 2.2 |
|---|
| HP | 130 |
|---|
| Overall length (mm) | 4863 |
|---|
| Overall height (mm) | 2070 |
|---|
| Overall width (mm) | 1974 |
|---|
| Wheelbase (mm) | 2933 |
|---|
| Loading Height (mm) | 619 |
|---|
| Rear Door Width (mm) | 1540 |
|---|
| Rear Door Height (mm) | 1370 |
|---|
| Load Length (mm) | 2582 |
|---|
| Load Width Max (mm) | 1762 |
|---|
| Load Height (mm) | 1430 |
|---|
| Load Volume (m3) | 6.5 |
|---|
| Gross Payload (Kg) | 991 |
|---|
| Gross Vehicle Weight (Kg) | 2600 |
|---|
| Kerb Weight (Kg) | 1609 |
|---|
| Towing Limit (Kg) | 500 |
|---|
Transit 330 2.2 TDCi MWB m/r 110| | Transit 330 2.2 TDCi MWB m/r 110 |
|---|
| Engine size (litres) | 2.2 |
|---|
| HP | 110 |
|---|
| Overall length (mm) | 5230 |
|---|
| Overall height (mm) | 2363 |
|---|
| Overall width (mm) | 1974 |
|---|
| Wheelbase (mm) | 3300 |
|---|
| Loading Height (mm) | 596 |
|---|
| Rear Door Width (mm) | 1540 |
|---|
| Rear Door Height (mm) | 1666 |
|---|
| Load Length (mm) | 2949 |
|---|
| Load Width Max (mm) | 1762 |
|---|
| Load Height (mm) | 1745 |
|---|
| Load Volume (m3) | 9.1 |
|---|
| Gross Payload (Kg) | 1560 |
|---|
| Gross Vehicle Weight (Kg) | 3300 |
|---|
| Kerb Weight (Kg) | 1740 |
|---|
| Towing Limit (Kg) | 1200 |
|---|
Transit 330 2.4 TDCi LWB h/r 100| | Transit 330 2.4 TDCi LWB h/r 100 |
|---|
| Engine size (litres) | 2.4 |
|---|
| HP | 100 |
|---|
| Overall length (mm) | 5680 |
|---|
| Overall height (mm) | 2606 |
|---|
| Overall width (mm) | 1974 |
|---|
| Wheelbase (mm) | 3750 |
|---|
| Loading Height (mm) | 710 |
|---|
| Rear Door Width (mm) | 1540 |
|---|
| Rear Door Height (mm) | 1796 |
|---|
| Load Length (mm) | 3399 |
|---|
| Load Width Max (mm) | 1762 |
|---|
| Load Height (mm) | 1885 |
|---|
| Load Volume (m3) | 11.3 |
|---|
| Gross Payload (Kg) | 1362 |
|---|
| Gross Vehicle Weight (Kg) | 3300 |
|---|
| Kerb Weight (Kg) | 1938 |
|---|
| Towing Limit (Kg) | 2200 |
|---|
Transit 330 2.4 TDCi LWB h/r 140| | Transit 330 2.4 TDCi LWB h/r 140 |
|---|
| Engine size (litres) | 2.4 |
|---|
| HP | 140 |
|---|
| Overall length (mm) | 5680 |
|---|
| Overall height (mm) | 2606 |
|---|
| Overall width (mm) | 1974 |
|---|
| Wheelbase (mm) | 3750 |
|---|
| Loading Height (mm) | 710 |
|---|
| Rear Door Width (mm) | 1540 |
|---|
| Rear Door Height (mm) | 1796 |
|---|
| Load Length (mm) | 3399 |
|---|
| Load Width Max (mm) | 1762 |
|---|
| Load Height (mm) | 1885 |
|---|
| Load Volume (m3) | 11.3 |
|---|
| Gross Payload (Kg) | 1337 |
|---|
| Gross Vehicle Weight (Kg) | 3300 |
|---|
| Kerb Weight (Kg) | 1963 |
|---|
| Towing Limit (Kg) | 2700 |
|---|
Transit 330 2.4 TDCi MWB h/r 140| | Transit 330 2.4 TDCi MWB h/r 140 |
|---|
| Engine size (litres) | 2.4 |
|---|
| HP | 140 |
|---|
| Overall length (mm) | 5230 |
|---|
| Overall height (mm) | 2611 |
|---|
| Overall width (mm) | 1974 |
|---|
| Wheelbase (mm) | 3300 |
|---|
| Loading Height (mm) | 710 |
|---|
| Rear Door Width (mm) | 1540 |
|---|
| Rear Door Height (mm) | 1796 |
|---|
| Load Length (mm) | 2929 |
|---|
| Load Width Max (mm) | 1762 |
|---|
| Load Height (mm) | 1885 |
|---|
| Load Volume (m3) | 9.8 |
|---|
| Gross Payload (Kg) | 1370 |
|---|
| Gross Vehicle Weight (Kg) | 3300 |
|---|
| Kerb Weight (Kg) | 1930 |
|---|
| Towing Limit (Kg) | 2700 |
|---|
Transit 330 2.4 TDCi MWB m/r 140| | Transit 330 2.4 TDCi MWB m/r 140 |
|---|
| Engine size (litres) | 2.4 |
|---|
| HP | 140 |
|---|
| Overall length (mm) | 5230 |
|---|
| Overall height (mm) | 2397 |
|---|
| Overall width (mm) | 1974 |
|---|
| Wheelbase (mm) | 3300 |
|---|
| Loading Height (mm) | 715 |
|---|
| Rear Door Width (mm) | 1540 |
|---|
| Rear Door Height (mm) | 1566 |
|---|
| Load Length (mm) | 2949 |
|---|
| Load Width Max (mm) | 1762 |
|---|
| Load Height (mm) | 1645 |
|---|
| Load Volume (m3) | 8.5 |
|---|
| Gross Payload (Kg) | 1392 |
|---|
| Gross Vehicle Weight (Kg) | 3300 |
|---|
| Kerb Weight (Kg) | 1908 |
|---|
| Towing Limit (Kg) | 2700 |
|---|
