Below are the specifications of the range of Ford Transit Connect vans.
Transit Connect 200 1.8 TDCi SWB 75| | Transit Connect 200 1.8 TDCi SWB 75 |
|---|
| Engine size (litres) | 1.8 |
|---|
| HP | 75 |
|---|
| Overall length (mm) | 4308 |
|---|
| Overall height (mm) | 1814 |
|---|
| Overall width (mm) | 1795 |
|---|
| Wheelbase (mm) | 2664 |
|---|
| Loading Height (mm) | 598 |
|---|
| Rear Door Width (mm) | 1293 |
|---|
| Rear Door Height (mm) | 1145 |
|---|
| Load Length (mm) | 1739 |
|---|
| Load Width Max (mm) | 1490 |
|---|
| Load Height (mm) | 1193 |
|---|
| Load Volume (m3) | 2.8 |
|---|
| Gross Payload (Kg) | 625 |
|---|
| Gross Vehicle Weight (Kg) | 2040 |
|---|
| Kerb Weight (Kg) | 1415 |
|---|
| Towing Limit (Kg) | 800 |
|---|
Transit Connect 200 1.8 TDCi SWB 90L| | Transit Connect 200 1.8 TDCi SWB 90L |
|---|
| Engine size (litres) | 1.8 |
|---|
| HP | 90 |
|---|
| Overall length (mm) | 430.8 |
|---|
| Overall height (mm) | 1814 |
|---|
| Overall width (mm) | 1795 |
|---|
| Wheelbase (mm) | 2664 |
|---|
| Loading Height (mm) | 598 |
|---|
| Rear Door Width (mm) | 1293 |
|---|
| Rear Door Height (mm) | 1145 |
|---|
| Load Length (mm) | 1739 |
|---|
| Load Width Max (mm) | 1490 |
|---|
| Load Height (mm) | 1193 |
|---|
| Load Volume (m3) | 2.8 |
|---|
| Gross Payload (Kg) | 625 |
|---|
| Gross Vehicle Weight (Kg) | 2040 |
|---|
| Kerb Weight (Kg) | 1415 |
|---|
| Towing Limit (Kg) | 800 |
|---|
Transit Connect 220 1.8 TDCi SWB 110 LX| | Transit Connect 220 1.8 TDCi SWB 110 LX |
|---|
| Engine size (litres) | 1.8 |
|---|
| HP | 110 |
|---|
| Overall length (mm) | 4308 |
|---|
| Overall height (mm) | 1814 |
|---|
| Overall width (mm) | 1795 |
|---|
| Wheelbase (mm) | 2664 |
|---|
| Loading Height (mm) | 598 |
|---|
| Rear Door Width (mm) | 1293 |
|---|
| Rear Door Height (mm) | 1145 |
|---|
| Load Length (mm) | 1739 |
|---|
| Load Width Max (mm) | 1490 |
|---|
| Load Height (mm) | 1193 |
|---|
| Load Volume (m3) | 2.8 |
|---|
| Gross Payload (Kg) | 825 |
|---|
| Gross Vehicle Weight (Kg) | 2240 |
|---|
| Kerb Weight (Kg) | 1415 |
|---|
| Towing Limit (Kg) | 800 |
|---|
Transit Connect 220 1.8 TDCi SWB 110L| | Transit Connect 220 1.8 TDCi SWB 110L |
|---|
| Engine size (litres) | 1.8 |
|---|
| HP | 110 |
|---|
| Overall length (mm) | 4308 |
|---|
| Overall height (mm) | 1814 |
|---|
| Overall width (mm) | 1795 |
|---|
| Wheelbase (mm) | 2664 |
|---|
| Loading Height (mm) | 598 |
|---|
| Rear Door Width (mm) | 1293 |
|---|
| Rear Door Height (mm) | 1145 |
|---|
| Load Length (mm) | 1739 |
|---|
| Load Width Max (mm) | 1490 |
|---|
| Load Height (mm) | 1193 |
|---|
| Load Volume (m3) | 2.8 |
|---|
| Gross Payload (Kg) | 825 |
|---|
| Gross Vehicle Weight (Kg) | 2240 |
|---|
| Kerb Weight (Kg) | 1415 |
|---|
| Towing Limit (Kg) | 800 |
|---|
Transit Connect 230 1.8TDCi LWB 110 LX| | Transit Connect 230 1.8TDCi LWB 110 LX |
|---|
| Engine size (litres) | 1.8 |
|---|
| HP | 110 |
|---|
| Overall length (mm) | 4555 |
|---|
| Overall height (mm) | 1961 |
|---|
| Overall width (mm) | 1795 |
|---|
| Wheelbase (mm) | 2912 |
|---|
| Loading Height (mm) | 601 |
|---|
| Rear Door Width (mm) | 1293 |
|---|
| Rear Door Height (mm) | 1316 |
|---|
| Load Length (mm) | 1986 |
|---|
| Load Width Max (mm) | 1490 |
|---|
| Load Height (mm) | 1364 |
|---|
| Load Volume (m3) | 3.7 |
|---|
| Gross Payload (Kg) | 900 |
|---|
| Gross Vehicle Weight (Kg) | 2340 |
|---|
| Kerb Weight (Kg) | 1440 |
|---|
| Towing Limit (Kg) | 800 |
|---|
Transit Connect 230 1.8TDCi LWB 90 L| | Transit Connect 230 1.8TDCi LWB 90 L |
|---|
| Engine size (litres) | 1.8 |
|---|
| HP | 90 |
|---|
| Overall length (mm) | 4555 |
|---|
| Overall height (mm) | 1961 |
|---|
| Overall width (mm) | 1795 |
|---|
| Wheelbase (mm) | 2912 |
|---|
| Loading Height (mm) | 601 |
|---|
| Rear Door Width (mm) | 1293 |
|---|
| Rear Door Height (mm) | 1316 |
|---|
| Load Length (mm) | 1986 |
|---|
| Load Width Max (mm) | 1490 |
|---|
| Load Height (mm) | 1364 |
|---|
| Load Volume (m3) | 3.7 |
|---|
| Gross Payload (Kg) | 900 |
|---|
| Gross Vehicle Weight (Kg) | 2340 |
|---|
| Kerb Weight (Kg) | 1440 |
|---|
| Towing Limit (Kg) | 800 |
|---|
